AGA-60 Double-Guided Low Profile Angular Gripper

Product Inquiry

  • This field is for validation purposes and should be left unchanged.

Download Product PDF
Download CAD File

Product Specifications

Design: Angular

Stroke: 0-180° adj

Gripping Force @ 80 PSI [5.5 BAR]
Closing: 820 lbs [3600 N]
Opening: 691 lbs [3070 N]

Time:
Close: 0.5 sec [0.5 sec]
Open: 0.5 sec [0.5 sec]

Pressure Range:
Low/High 10-120 PSI [.7-8 BAR]

Temperature Range:
Low/High -20°/180°F [-28°/80°C]

Side Play:
± 0.001 [.03 mm]

Repeatability from Center:
± 0.002 [.06 mm]

Loading Capacity: Static – Dynamic

Max Tensile T
1200 lbs 400 lbs
[5330 N] [1780 N]

Max Compressive C
1200 lbs 400 lbs
[5330 N] [1780 N]

Max Moment Mx
930 in/lb 310 in/lb
[105 Nm] [35 Nm]

Max Moment My
880 in/lb 276 in/lb
[99.5 Nm] [31.2 Nm]

Max Moment Mz
880 in/lb 276 in/lb
[99.5 Nm] [31.2 Nm]

Material: High Strength,Hard Coated aluminum
bronze alloys, Steel

Weight: 6 lbs [2.7 kg]

Piston Diameter: 3.0 in [76 mm]

Features & Benefits

  • Grippers provide up to 180º of angular jaw travel allowing the jaws to completely retract from the work area eliminating another required axis of travel.
  • High gripping force to weight ratio.
  • Compact design with long, adjustable stroke.
  • Units are permanently lubricated for non-lube air operation, allowing for compliance with OSHA regulation.
  • Proximity sensors are available to monitor open and closed position of the jaws.
  • AGA is fully field repairable for cost savings and minimum down time.
  • The gripper body has two mounting surfaces with dowel pin holes to provide accurate mounting in a variety of positions.

3-D Interactive Preview
