AGPS-2-1

AGPS-2-1 Parallel Gripper – Single Finger, One Fixed Jaw

Features & Benefits

  • T-Slot bearing support for the carriage and end plate offers superior load bearing performance throughout the stroke.
  • Compact lightweight unit with built-in air cylinder.
  • Piston seals are U-cup type for long service life.
  • Standard built-in stroke adjustment and stroke lock for precise, repetitive operation.
  • Hall Effect sensors are available to monitor stroke position.
  • Multiple mounting surfaces on the body and endplate with threaded and counterbored holes for easy mounting choices.

DOWNLOAD PRODUCT PDF
DOWNLOAD CAD FILE

PRODUCT SPECIFICATIONS

Design: Built-in air cylinder T-slot slide

Stroke: 0.5 in [12.7 mm]

Thrust Force @ 80 PSI [5.5 BAR]

Extended: 35 lbs [155 N]

Retract: 33 lbs [146 N]

Recommended Speed: 2-12 in/sec [0.5-.3m/sec]

Pressure Range:
Low/High 20-120 PSI [1.4-8 BAR]

Temperature Range:
Low/High -20°/150°F [-28°/80°C]

Side Play: ± 0.001 [.03 mm]

Maximum Payload: 7 lbs [3.2 kg]

Material: High Strength, Aluminum Alloys, Bronze

Weight: 4.2 oz [120 g]

Piston Diameter: .750 in [19 mm]
